Product Categories
The product has two types: Halogen Polycarbonate and non-halogen PC.
Product Features
It has good light-shielding property and reaches UL94-VO grade,which is in line with ROHS standard.Environmentally safe,with good insulation and impact resistance,temperature resistance.
Product Applications
It is widely used for laminating and insulating materials of power supply devices, TV screens, airplanes and so on.
Product Specifications
|
产品代码Code
|
颜色Color
|
表面纹理Texture
|
厚度(mm)Thickness
|
宽度(mm)Width
|
安全标准Safety Standards
|
|
DFPCR24-B
|
黑色 Black
|
哑光/中砂
matte/velvet
|
0.125~2.000
(0.005”～0.079”)
|
≤1300 (≤51”)
|
防火UL94
FR VTM-0&V-0
|
|
DFPCR34-B
|
黑色 Black
|
细砂/中砂
velvet/velvet
|
|
厚度公差
Gauge Variation
|
d<0.25mm ±10um
0.5<d<1.2mm ±25um
|
0.25≤d≤0.5mm±15um d≥1.2mm±35um
|
Physical Properties
|
特性PROPERTY
|
测试方法Tes Method
|
单位Units
|
测试值Value
|
|
物理性PHYSICAL
|
|
比重Specific Gravity
|
ASTM D792
|
g/cm³
|
1.2
|
|
平均吸水率Water Absorption Equilibrium,24HRS
|
ASTM D570
|
%
|
0.23
|
|
机械性MECHANICAL
|
|
拉伸强度Tensile Strength
|
ASTM D882
|
Mpa
|
>55
|
|
极限延伸率Elongation Ultimate
|
ASTM D882
|
%
|
≥50
|
|
耐温性THERMAL
|
|
维卡软化点Vicat Softening Temperature
|
ASTM D1525
|
℃
|
135
|
|
热收缩率Strain Relief @135℃
|
ASTM D1204
|
%
|
≤1
|
|
电气性ELECTRICAL
|
|
介电强度Dielectric Strength(@10mils)
|
ASTM D149
|
KV/mm
|
>20
|
|
体积绝缘Volume Resistivity@25℃,50%RH
|
ASTM D257
|
Q-cm
|
>1×10¹6
|
|
表面绝缘Surface Resistivity@25℃,50%RH
|
ASTM D257
|
Ω
|
>1×10¹5
|
|
阻燃性FLAMMABILITY
|
|
UL防火等级UL Flammability @≥10 mils
|
UL94
|
-----
|
VTM0/VO
|
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
