Product Features
The product is transparent, no impurities or no fish eyes, It can provide excellent optical conductivity, high heat resistance, flexible folding resistance, excellent dimensional stability and low internal stress.
Product Applications
The product is widely used in monitors, notebooks computers, navigating instruments, cell phones, light keyboards, light boxes, nameplates and light fixtures.
Product Specifications
| Code |
Color |
Texture |
Thickness(mm) |
Width(mm) |
| DFPCR11 |
Natural |
Polished / Polished |
0.100 ~ 3.500 ( 0.004” ~ 0.138” ) |
915 & 1220 ( 3’ ~ 4’ ) |
| Gauge Variation |
<0.25mm ±10%
≧0.25mm ±5% |
Physical Properties
| Items |
Tes Method |
Units |
Value |
|
PHYSICAL
|
Specific Gravity |
ASTM D792 |
g/cm³ |
1.2 |
| Light Transmition |
ASTM D1003 |
% |
89-92 |
| Water Absorption Equilibrium, 24 HRS |
ASTM D570 |
% |
0.35 |
|
MECHANICAL
|
Tensile Strength |
ASTM D882 |
Mpa |
≧60 |
| Elongation Ultimate |
ASTM D882 |
% |
≧90 |
|
THERMAL
|
Vicat Softening Temperature |
ASTM D1525 |
℃ |
135 |
| Strain Relief @135℃ |
ASTM D1204 |
% |
≦3 |
|
ELECTRICAL
|
Dielectric Strength (@10mils) |
ASTM D149 |
KV/mm |
≧20 |
| Volume Resistivity @25℃, 50%RH |
ASTM D257 |
Ω-cm |
>1x1017 |
| Surface Resistivity @25℃, 50%RH |
ASTM D257 |
Ω |
>1x1015 |
|
FLAMMABILITY
|
UL Flamability |
UL BULLETIN 94 |
|
|
| @≧10mils |
|
UL 94 |
V-0 |
| Oxygen Index @10 mils |
ASTM D2863 |
% |
33 |
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
