Product CategoriesWe can offer different textures, such as fine velvet, velvet and suede. The opposite side can be matte, fine matte or polished.
Product FeaturesThe product with textures has properties of excellent scratching resistance and low gloss. It also has excellent physical and mechanical properties. It has thermal, insulation and flame retarding properties as well.
Product ApplicationsIt is used for viewing window, AV/OA, panels, electrical insulation, printing nameplates, digital photo frames, sport helmets and more.
Specification
|
Code
|
Color
|
Texture
|
（mm）Thickness
|
（mm）Width
|
|
DFPC24
|
Natural
|
matte / velvet
|
0.050 ~ 1.00 ( 0.002” ~ 0.040” )
|
915 & 1220 ( 3’ ~ 4’ ) 可以分切 Slitting available
|
|
DFPC23
|
matte / fine velvet
|
|
DFPC25
|
matte / suede
|
|
DFPC24F
|
Fine matte / velvet
|
0.175~1.500 (0.007”~ 0.060” )
|
|
DFPC23F
|
Fine matte / fine velvet
|
|
DFPC12
|
Polished / Matte
|
0.050~1.00 (0.002”~0.040”)
|
|
DFPC12F
|
Polished / Fine matte
|
0.250~1.500 ( 0.010” ~ 0.060”)
|
|
DFPC14
|
Polished / Velvet
|
|
Gauge Variation
|
<0.25mm ±10%
≧0.25mm ±5%
|
Typical Property Values
|
Items
|
Test Methods
|
Units
|
Value
|
|
PHYSICAL
|
|
Specific Gravity
|
ASTM D792
|
g/cm³
|
1.2
|
|
Water Absorption Equilibrium, 24 HRS
|
ASTM D570
|
%
|
0.35
|
|
MECHANICAL
|
|
Tensile Strength
|
ASTM D882
|
Mpa
|
≧55
|
|
Elongation Ultimate
|
ASTM D882
|
%
|
≧90
|
|
THERMAL
|
|
Vicat Softening Temperature
|
ASTM D1525
|
℃
|
135
|
|
Strain Relief @135℃
|
ASTM D1204
|
%
|
≦1
|
|
ELECTRICAL
|
|
Dielectric Strength (@10mils)
|
ASTM D149
|
KV/mm
|
≧30
|
|
Volume Resistivity @25℃, 50%RH
|
ASTM D257
|
Ω-cm
|
>1x1017
|
|
Surface Resistivity @25℃, 50%RH
|
ASTM D257
|
Ω
|
>1x1015
|
|
FLAMMABILITY
|
|
UL Flamability
|
UL BULLETIN 94
|
|
|
|
@≧20mils （≧0.25mm）
|
|
UL 94
|
V-2
|
