Product Features
This product has many colors such as black, white, gray and more. It is good in appearance, flame-retardant and high glossy. The surface can be printing, anti-scratching, and the color is uniform. It has good plasticity properties.
Product Applications
The product is used for power supplies, TV monitors, airplanes and insulation shielding materials. It is also used for nameplates, automotive dashboards and water-electricity meters.
Product Specifications
|
产品代码Code
|
颜色Color
|
表面纹理Texture
|
厚度(mm)Thickness
|
宽度(mm)Width
|
|
DFPC24
|
指定 Specified
|
哑光/中砂 Matte/velvet
|
0.100~2.000
(0.004”～0.079”)
|
≤1300 (≤51”)
|
|
厚度公差
Gauge Variation
|
d<0.25mm ±10um 0.25≤d≤0.5mm±15um 0.5<d<1.2mm ±25um d≥1.2mm±35um
|
Physical Properties
|
特性PROPERTY
|
测试方法Tes Method
|
单位Units
|
测试值Value
|
|
物理性PHYSICAL
|
|
比重Specific Gravity
|
ASTM D792
|
g/cm³
|
1.2
|
|
平均吸水率Water Absorption Equilibrium,24HRS
|
ASTM D570
|
%
|
0.23
|
|
机械性MECHANICAL
|
|
拉伸强度Tensile Strength
|
ASTM D882
|
Mpa
|
>55
|
|
极限延伸率Elongation Ultimate
|
ASTM D882
|
%
|
≥50
|
|
耐温性THERMAL
|
|
维卡软化点Vicat Softening Temperature
|
ASTM D1525
|
℃
|
135
|
|
热收缩率Strain Relief @135℃
|
ASTM D1204
|
%
|
≤1
|
|
电气性ELECTRICAL
|
|
介电强度Dielectric Strength(@10mils)
|
ASTM D149
|
KV/mm
|
≥20
|
|
体积绝缘Volume Resistivity@25℃,50%RH
|
ASTM D257
|
Q-cm
|
>1×10¹6
|
|
表面绝缘Surface Resistivity@25℃,50%RH
|
ASTM D257
|
9
|
>1x1015
|
|
阻燃性FLAMMABILITY
|
|
UL防火等级UL Flammability @≥20 mils
|
UL94
|
----
|
V2-VO
|
|
环保指标
Environment
Protection Index
|
汞 Hg
|
六价铬 Cr(VI)
|
镉
|
第
|
多溴联苯 PBBs
|
多溴联苯醚 PBDEs
|
全氟辛烷磺酸 PFOS
|
全氟辛烷(铵) PFOA
|
|
DFPC24
|
N.D
|
N.D
|
N.D
|
N.D
|
N.D
|
N.D
|
N.D
|
N.D
|
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
