Product Features
Through co-extrusion compounding,the high impact strength,bending resistance and good hardness and abrasion resistance of PC materials are combined to improve the overall toughness of the material;high-definition transparency,high gloss,printability,texture- manufactured.It can get a good streamer and bright glass effect.After hardening,the drop resistance is greatly improved,and there is no signal shielding,which can perfectly replace the glass for the back cover of the mobile phone.
Product Applications
Universal base film for various high pressure and hot pressing IMD/FIM forming processes, such as automotive control parts,interior parts,dashboards,mobile phones,monitors,bags, helmets,hardened for mobile phone back cover,touch screen.
Product Specifications
|
产品代码Code
|
类别Type
|
颜色Color
|
表面纹理Texture
|
厚度(mm)Thickness
|
宽度(mm)Width
|
|
DFPM12 DFPM11
|
非抗冲
non-impact board
|
本色 Natural
|
光面/光面
Polished/Polished
|
0.070~3.000
(0.003”~0.118”)
|
≤1320 (≤52”)
|
|
DFPM13 DFPM23
|
抗冲
impact board
|
|
DFPM13 H1 DFPM13 H2
|
加硬
harden board
|
|
厚度公差
Gauge Variation
|
d<0.25±10um 0.25≤d≤0.5±15um 0.5<d<1.2±25um d≥1.2±35um
|
Thickness range: 0.175mm、0.2mm、0.25mm;
Customized products available upon inquiries ranging above 0.25mm specifications.
Web width:930mm
Customized width upon request
Physical Properties
|
项目Items
|
测试方法Tes Method
|
单位Units
|
测试值Value
|
|
物理性PHYSICAL
|
|
比重Specific Gravity
|
ASTM D792
|
g/cm³
|
1.2
|
|
透光率Light Transmition
|
ASTM D1003
|
%
|
≥90
|
|
雾度Haze
|
ATSM D1003
|
%
|
<0.5
|
|
黄色指数Yellowness Index
|
ASTM D1925
|
-----
|
<1.0
|
|
机 械 性 M E C H A N I CA L
|
|
铅笔硬度
Pencil Hardness @750g
|
PMMA
|
ATSM D3363
|
-----
|
HB~H
|
|
拉伸强度Tensile Strength
|
ASTM D882
|
Mpa
|
≥55
|
|
落球冲击强度Impact Strength
|
112g Bullet shape
|
mm
|
>100
|
|
附着力Adhesion
|
ATSM D3359
|
-----
|
5B
|
|
耐温性THERMAL
|
|
热收缩率Strain Relief @135℃
|
ASTM D1204
|
%
|
≤1
|
|
微卡软化点Vicat softening point
|
ISO 306/B50
|
℃
|
140
|
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
