Product Introduction
The PPO film has high temperature performance, good mechanical strength ，radiation, chemical resistance ，electrical insulation and ease of processing.
Product Specifications
| Code |
Color |
Texture |
Thickness(mm) |
Width(mm) |
|
PPO
|
Natural |
Polished/Polished
|
0.05~0.5
|
≤1100 |
Customers can customize according to their requirements within the above range.
Physical Properties
| PROPERTY |
Tes Method |
Units |
Value |
|
PHYSICAL
|
Density |
ASTM D792 |
g/cm3 |
1.06 |
| Water absorption |
ASTM D570（ 23℃/24h） |
% |
0.06 |
|
MECHANICAL
|
Tensile Strength |
ASTM D882 |
MD（ MPa） |
69 |
| ASTM D882 |
TD（ MPa） |
56 |
| Elongation Ultimate |
ASTM D882 |
MD % |
120 |
| ASTM D882 |
TD % |
141 |
| Tensile modulus |
ASTM D882 |
MD（ MPa） |
1791 |
| ASTM D882 |
TD（ MPa） |
1551 |
|
THERMAL
|
Temperature ofdeflection |
ASTM D648 ( 1.82MPa,3.2mm) |
℃ |
182 |
| Shrinkage |
ISO 11501（ 200℃,30min） |
MD % |
1 |
| TD % |
0.5 |
|
ELECTRICAL
|
Volume |
ASTM D257 |
Ω·cm |
1016 |
| Dielectric Constant |
ASTM D150(10MHz) |
|
2.8 |
Remarks: The above data is the test value of the laboratory, non-guaranteed value, for reference only.
