Product Features
This product has very good reflective properties with its reflectivity reaching 98%. It can improve the uniformity of the light source.
Product Applications
The product is widely used in monitors, notebooks computers, navigating instruments, cell phones, light keyboards, light boxes, nameplates and light fixtures.
Product Specifications
| Code |
Color |
Texture |
Thickness(mm) |
Width(mm) |
| DFPCR11 |
white |
Polished / Polished |
0.100 ~ 3.500 ( 0.004” ~ 0.138” ) |
915 & 1220 ( 3’ ~ 4’ ) |
| Gauge Variation |
<0.25mm ±10%
≧0.25mm ±5% |
Physical Properties
| Items |
Tes Method |
Units |
Value |
|
PHYSICAL
|
Specific Gravity |
ASTM D792 |
g/cm³ |
1.32 |
| Light Transmition |
ASTM D1003 |
% |
≧95 |
|
MECHANICAL
|
Tensile Strength |
ASTM D882 |
Mpa |
≧60 |
| Elongation Ultimate |
ASTM D882 |
% |
≧90 |
|
THERMAL
|
Vicat Softening Temperature |
ASTM D1525 |
℃ |
135 |
| Strain Relief @135℃ |
ASTM D1204 |
% |
≦1 |
|
ELECTRICAL
|
Dielectric Strength (@10mils) |
ASTM D149 |
KV/mm |
≧20 |
| Volume Resistivity @25℃, 50%RH |
ASTM D257 |
Ω-cm |
>1x1017 |
| Surface Resistivity @25℃, 50%RH |
ASTM D257 |
Ω |
>1x1015 |
|
FLAMMABILITY
|
UL Flamability |
UL BULLETIN 94 |
|
|
| @≧10mils |
|
UL 94 |
V-2 |
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
