Product Classification
We can offer different textures,such as fine velvet,velvet and suede. The opposite side can be matte or polished.
Product Features
A variety of different surface textures,meet the needs of different transmittance,haze,delicate touch,low gloss,good visual comfort, excellent bending,wear resistance,heat resistance.
Product Applications
Widely used in lamps,car dashboards,buttons,LED displays,travel bags,advertising decoration,electronic displays,etc.
Product Specifications
|
产品代码Code
|
颜色Color
|
表面纹理Texture
|
厚度(mm)Thickness
|
宽度(mm)Width
|
|
DFPC24
|
本色 Natural
|
哑光/中砂matte/velvet
|
0.040~1.500
(0.002”～0.060”)
|
≤1300 (≤51”)
|
|
DFPC23
|
哑光细砂matte/fine velvet
|
|
DFPC25
|
哑光/粗砂matte/suede
|
|
DFPC12
|
光面/哑面Polished/Matte
|
|
DFPC14
|
光面/中砂Polished/Velvet
|
|
厚度公差
Gauge Variation
|
d<0.25mm ±10um 0.25≤d≤0.5mm±15um
0.5<d<1.2mm ±25um d≥1.2mm±35um
|
Customers can customize according to their requirements within the above range.
Physical Properties
|
特性PROPERTY
|
测试方法Tes Method
|
单位Units
|
测试值Value
|
|
物理性PHYSICAL
|
|
比重Specific Gravity
|
ASTM D792
|
g/cm³
|
1.2
|
|
平均吸水率Water Absorption Equilibrium,24HRS
|
ASTM D570
|
%
|
0.23
|
|
机械性MECHANICAL
|
|
拉伸强度Tensile Strength
|
ASTM D882
|
Mpa
|
≥55
|
|
极限延伸率Elongation Ultimate
|
ASTM D882
|
%
|
≥90
|
|
耐温性THERMAL
|
|
维卡软化点Vicat Softening Temperature
|
ASTM D1525
|
℃
|
135
|
|
热收缩率Strain Relief @135℃
|
ASTM D1204
|
%
|
≤1
|
|
电气性ELECTRICAL
|
|
介电强度Dielectric Strength(@10mils)
|
ASTM D149
|
KV/mm
|
30
|
|
体积绝缘Volume Resistivity@25℃,50%RH
|
ASTM D257
|
Q-cm
|
>1×10¹6
|
|
表面绝缘Surface Resistivity@25℃,50%RH
|
ASTM D257
|
9
|
>1×10¹⁵
|
|
阻燃性FLAMMABILITY
|
|
UL防火等级UL Flammability @≥20 mils
|
UL94
|
-----
|
V-2
|
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
