Product Features
Diverse colors,good flexibility,never fade,strong adhesion, good wear resistance,temperature resistance and dimensional stability.
Product Applications
Products are widely used for: sun hats, ski goggles, nameplates, electric plates printing, sport helmets and so on.
Product Specifications
| Code |
Color |
Texture |
Thickness(mm) |
Width(mm) |
|
DFPC11C
|
Specified |
Polished/Polished
|
0.100 ~ 3.500 ( 0.004” ~ 0.138” )
|
1300 ( 51'' ） |
| Gauge Variation |
<0.25mm ±10%
≧0.25mm ±5% |
Customers can customize according to their requirements within the above range.
Physical Properties
| Items |
Tes Method |
Units |
Value |
|
PHYSICAL
|
Specific Gravity |
ASTM D792 |
g/cm³ |
1.2 |
| Light Transmition |
ASTM D1003 |
% |
89-90 |
| Water Absorption Equilibrium, 24 HRS |
ASTM D570 |
% |
0.35 |
|
MECHANICAL
|
Tensile Strength |
ASTM D882 |
Mpa |
≧60 |
| Elongation Ultimate |
ASTM D882 |
% |
≧90 |
|
THERMAL
|
Vicat Softening Temperature |
ASTM D1525 |
℃ |
135 |
| Strain Relief @135℃ |
ASTM D1204 |
% |
≦1 |
|
ELECTRICAL
|
Dielectric Strength (@10mils) |
ASTM D149 |
KV/mm |
≧30 |
| Volume Resistivity @25℃, 50%RH |
ASTM D257 |
Ω-cm |
>1x1017 |
| Surface Resistivity @25℃, 50%RH |
ASTM D257 |
Ω |
>1x1015 |
|
FLAMMABILITY
|
UL Flamability |
UL BULLETIN 94 |
|
|
| @≧20mils （Thickness≧0.25mm） |
|
UL 94 |
V-2 |
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
