Product Categories
The product has two types: Halogen Polycarbonate and non-halogen PC.
Product Features
It has good shading performance and complies with ROHS standard. It is non-halogen insulation material of excellent heat resistance.
Product Applications
It is widely used for laminating and insulating materials of power supply devices, TV screens, airplanes and so on.
Product Specifications
| Code |
Color |
Texture |
Thickness(mm) |
Width(mm) |
| DFPCR24FB |
Black |
Fine matte / Velvet |
0.100 ~ 1.500 ( 0.004” ~ 0.060” ) |
UL94 FR VTM-0&V-0 |
| DFPCR24FB |
Black |
Matte / Velvet |
0.250 ~ 1.500 ( 0.010” ~ 0.060” ) |
| DFPCR12B |
Black |
Polished/ Matte |
0.05~0.25 ( 0.002”~0.010”) |
| Gauge Variation |
<0.25mm ±10%
≧0.25mm ±5% |
Physical Properties
| Items |
Tes Method |
Units |
Value |
|
PHYSICAL
|
Specific Gravity |
ASTM D792 |
g/cm³ |
1.32 |
| Light Transmition |
ASTM D1003 |
% |
0.35 |
|
MECHANICAL
|
Tensile Strength |
ASTM D882 |
Mpa |
≧55 |
| Elongation Ultimate |
ASTM D882 |
% |
≧50 |
|
THERMAL
|
Vicat Softening Temperature |
ASTM D1525 |
℃ |
135 |
| Strain Relief @135℃ |
ASTM D1204 |
% |
≦3 |
|
ELECTRICAL
|
Dielectric Strength (@10mils) |
ASTM D149 |
KV/mm |
≧20 |
| Volume Resistivity @25℃, 50%RH |
ASTM D257 |
Ω-cm |
>1x1016 |
| Surface Resistivity @25℃, 50%RH |
ASTM D257 |
Ω |
>1x1015 |
|
FLAMMABILITY
|
UL Flamability |
UL BULLETIN 94 |
|
|
| @≧10mils |
|
UL 94 |
V-0 |
| Oxygen Index @10 mils |
ASTM D2863 |
% |
33 |
Notes: All the above data are acquired by standardized tests, which be used only for the references of the application of products.These data can not be regard as the assurance of physical properties in unstable application of products.
